Spartan Batteries

Advantages of Lithium (LiFePO4) Batteries

Easy Installation

Maintenance Free

Corrosion Free

No Distilled Water Needed

No Acid Spills

Lighter and Faster

± 150kgʼs Lighter

Easier on the Cart and Golf Course

3000 Charge Cycles

5 X more than Lead Acid Batteries

Warranty: 3000 Charge Cycles

Comparable Cost to the Lead Acid Alternatives

Significantly less KW hours used per charge

Specifications of our various models

ModelGLFP 38.4 – 80AhGLFP 38.4 – 100AhGLFP 51.2 – 60AhGLFP 51.2 – 80AhGLFP 51.2 – 80Ah
Nominal Voltage38.4 V38.4 V51.2 V51.2 V51.2 V
Rated Capacity80Ah100Ah60Ah80Ah100Ah
Max Charge Voltage58.4 V43.8 V58.4 V58.4 V58.4 V
Discharge Cut Off Voltage40.0 V30.0 V40.0 V40.0 V40.0 V
Max Charge Voltage50.0 A50.0 A50.0 A50.0 A50.0 A
Max Continuous
Discharging Current		80.0 A100.0 A80.0 A80.0 A100.0 A
Max Discharging Current
(30 seconds)		240.0 A300.0 A180.0 A240.0 A300.0 A
Weight40kg42kg42kg46kg46kg
CommunicationBluetoothBluetoothBluetoothBluetoothBluetooth
BMS ProtectionBluetooth capabilities plus solenoid
to protect the golf cart motor		Bluetooth capabilities plus solenoid
to protect the golf cart motor		Bluetooth capabilities plus solenoid
to protect the golf cart motor		Bluetooth capabilities plus solenoid
to protect the golf cart motor		Bluetooth capabilities plus solenoid
to protect the golf cart motor
Dimension (mm)456.5mm x 310mm x 250mm456.5mm x 310mm x 250mm456.5mm x 310mm x 250mm456.5mm x 310mm x 250mm456.5mm x 310mm x 250mm
BrandingSpartan inscribed sealed
plastic moulded battery case.		Spartan inscribed sealed
plastic moulded battery case.		Spartan inscribed sealed
plastic moulded battery case.		Spartan inscribed sealed
plastic moulded battery case.		Spartan inscribed sealed
plastic moulded battery case.
Operating TemperatureCharging: 0-45ºC
Discharging:-20-60ºC
Storage:0-45ºC		Charging: 0-45ºC
Discharging:-20-60ºC
Storage:0-45ºC		Charging: 0-45ºC
Discharging:-20-60ºC
Storage:0-45ºC		Charging: 0-45ºC
Discharging:-20-60ºC
Storage:0-45ºC		Charging: 0-45ºC
Discharging:-20-60ºC
Storage:0-45ºC
Charge Cycles3000 Charge Cycles
@80% Depth of Discharge (DOD) 		3000 Charge Cycles
@80% Depth of Discharge (DOD) 		3000 Charge Cycles
@80% Depth of Discharge (DOD) 		3000 Charge Cycles
@80% Depth of Discharge (DOD) 		3000 Charge Cycles
@80% Depth of Discharge (DOD)
Design Lifespan15-20 years15-20 years15-20 years15-20 years15-20 years
Warranty5 Years5 Years5 Years5 Years5 Years
Enquire Now
Enquire Now
Enquire Now
Enquire Now
Enquire Now

Setting the State of Charge (SOC)

Charge Indicator

  • Waiting Mode: LED (Red) or (Green) flash
  • Capacity <80%: LED (Red) flash
  • Capacity >80%: LED (Yellow) flash
  • Capacity >100%: LED (Green) on always

Technical Parameter

  • Models: TKY-500-3610
  • AC Input Voltage Range : 220 VAC ± 15%
  • Input Current: 7A
  • Full Load Efficiency: ≥ 93%
  • Output Voltage: 43.8V
  • Output Current: 10A

Technical Parameter

  • Models: TKY-600-4810
  • AC Input Voltage Range : 220 VAC ± 15%
  • Input Current: 7A
  • Full Load Efficiency: ≥ 93%
  • Output Voltage: 58.4V
  • Output Current: 10A
Setting the State of Charge (SOC) indicator for a Spartan 36-Volt Lithium Battery
Click here to download PDF
Setting the State of Charge (SOC) indicator for a Spartan 48-Volt Lithium Battery
Click here to download PDF
